Product details

Lifecycle

Obsolete Date 30-04-2025

Specifications

Processor number 1 processor included
Form factor 1U Rack
Included drives None ship standard, 8 SFF supported
Optical drive type None included
Power supply type 1x HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit
System fan features 5 standard hot plug fans
Included memory 32 GB (1 X 32 GB) RDIMM
NVDIMM capacity 16 GB
Warranty 3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at http://www.hpe.com/support
Weight 28.74 lb minimum, 35.86 lb maximum
Expansion slots 2 PCIe 3.0, for detailed descriptions reference the QuickSpecs
Product dimensions (metric) 4.29 x 43.46 x 70.7 cm
Weight 13.04 kg minimum, 16.27 kg maximum
Network controller HPE Ethernet 10Gb 2-port FLR-T BCM57416 Adapter
Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses)
NVDIMM type N/A
NVDIMM rank Single rank
Processor cache 27.5 MB L3
Processor core available 20 core
Processor speed 2.10 GHz
Product dimensions (imperial) 1.69 x 17.11 x 27.83 in
Memory type HPE DDR4 SmartMemory
Security Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
Storage controller HPE MR416i-a Gen10 Plus x16 Lanes 4GB Cache NVMe/SAS 12G Controller

Quickspecs

Overview

Does your data center need a secure, performance driven dense server that you can confidently deploy for virtualization, database, or high-performance computing? The HPE ProLiant DL360 Gen10 server delivers security, agility and flexibility without compromise. It supports the Intel® Xeon® Scalable processor with up to a 60% performance gain [1] and 27% increase in cores [2], along with 2933 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB [2] with an increase in performance of up to 82% [3]. With the added performance that Intel® Optane™ persistent memory 100 series for HPE [6], HPE NVDIMMs [7] and 10 NVMe bring, the HPE ProLiant DL360 Gen10 means business. Deploy, update, monitor and maintain with ease by automating essential server life cycle management tasks with HPE OneView and HPE Integrated Lights Out 5 (iLO 5). Deploy this 2P secure platform for diverse workloads in space constrained environments.

What’s new

HPE 800 Watt Flex Slot Titanium hot-plug power supply available for EMEA
Networking Choice (NC) server models provide greater flexibility in the primary networking selection.
Support for additional second generation Intel® Xeon® Scalable processors with improved price/performance.
Intel® Optane™ persistent memory 100 series for HPE offers the flexibility to deploy as dense memory or fast storage and enables per-socket memory capacity of up to 3.0 TB. [5]
Enhanced iLO 5 security features such as Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor.
HPE InfoSight provides a cloud-based analytics tool that predicts and prevents problems before your business is impacted.

Features

Intel® Optane™ persistent memory 100 series for HPE works with DRAM to provide fast, high capacity, cost effective memory and storage to transform big data workloads and analytics by enabling data to be stored, moved, and processed quickly. [6]

Embedded 4 x 1GbE (select models) or HPE FlexibleLOM and PCIe standup 1GbE, 10GbE, 25GbE, or 100GbE adapters provides flexibility of networking bandwidth and fabric so you can adapt and grow to changing business needs.

HPE iLO 5 enables the world’s most secure industry standard servers with HPE silicon root of trust technology to protect your servers from attacks, detect potential intrusions and recover your essential server firmware securely.

Industry-leading Performance with Versatile Compute

HPE ProLiant DL360 Gen10 server comes with a complete set of services offered by HPE Services, delivering confidence, reducing risk, and helping customers realize agility and stability.

Industry-Leading Serviceability and Deployment

Unmatched expandability is packed in a dense 1U rack design with up to three PCIe 3.0 slots.

With Runtime Firmware Verification the server firmware is checked every 24 hours verifying validity and credibility of essential system firmware. Secure Recovery allows server firmware to rollback to the to last known good state or factory settings after detection of compromised code.

The premium 10 SFF NVMe chassis backplane provides the ability to mix and match SAS/SATA and NVMe within the same chassis along with 8 + 2 SFF and 4 LFF chassis that supports new uFF and M.2 storage options.

Supporting the second generation Intel® Xeon® Scalable processor family with up to a 11% per-core performance gain [4] over first generation and with memory speeds up to 2933 MT/s.

New features include Server Configuration Lock that ensures secure transit and locks server hardware configuration, iLO Security Dashboard helps detect and address possible security vulnerabilities and Workload Performance Advisor provides server tuning recommendations for better server performance.

Additional security options are available with Trusted Platform Module (TPM) to prevent unauthorized access to server and securely stores artifacts used to authenticate the server platforms while the Intrusion Detection Kit logs and alerts when the server hood is removed.

HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.

Services provided under Operational Services include – HPE Flexible Capacity, HPE Datacenter Care, HPE Infrastructure Automation, HPE Campus Care, HPE Proactive Services and multi-vendor coverage.

HPE ProLiant DL360 Gen10 server supports industry-standard technology leveraging the Intel Xeon Scalable processor with up to 28 cores, 12G SAS and 3.0 TB of 2933 MT/s HPE DDR4 SmartMemory.

With support for up to 12 NVDIMMs per chassis and 2X capacity of first-generation HPE NVDIMMs, HPE ProLiant DL360 Gen10 server delivers up to 192 GB per system. [7]

Innovative Design for Flexibility and Choice
Security Innovations

Achieve greater capacity with flexible drive configurations with up to 10 SFF and four LFF drives along with an option to support up to 10 NVMe PCIe SSDs delivering enhanced performance, capacity, and reliability to meet various customer segments and workload requirements at the right economics.

Services from HPE Services simplifies the stages of the IT journey. Advisory and Transformation Services professionals understand customer challenges and design an enhanced solution. Professional Services enable rapid deployment of solutions and Operational Services provide ongoing support.

Media

HPE ProLiant DL360 Gen10 – Hardware Tour

HPE ProLiant DL360 Gen10 – Hardware Tour

Expandable & Versatile Server – the HPE ProLiant DL360

This new generation of HPE ProLiant DL360 Gen10 Server has been enhanced with so many new features that it has the compute power to meet power hungry businesses requiring a dense server.

ProLiand DL360 Gen 10 Exploded View

ProLiand DL360 Gen 10 Exploded View.

Compatible products

Documents

[1] HPE measurements: Up to 60% performance increase of Intel Xeon Platinum vs. previous generation E5-2600 v4 average gains of STREAM, LINPACK, SPEC CPU 2006 & SPEC CPU2017 metrics on HPE servers comparing 2-socket Intel Xeon Platinum 8280 to E5-2699 v4 family processors. Any difference in system hardware or software design or configuration may affect actual performance. April 2019.

[2] Up to 27% core increase of Intel Xeon Platinum versus previous generation comparing 2-socket Intel Xeon Platinum 8280 (28 cores) to E5-2699 v4 (22 cores). Calculation 28 cores / 22 cores = 1.27 = 27%. April 2019.

[3] Percentage compare Gen10 vs Gen9: Gen10 = 12 Channels x 2933 data rate x 8 bytes = 281 GB/sec. Gen 9 = 8 channels x 2400 x 8 bytes = 154 GB/Sec. 281/154 = 1.82 or Gen10 is 82% greater bandwidth. Any difference in system hardware or software design or configuration may affect actual performance. April 2019.

[4] HPE measurements: Up to 11% performance increase of Intel Xeon Platinum vs. previous generation average gains of STREAM, LINPACK, & SPEC CPU2017 metrics on HPE servers comparing 2-socket Intel Xeon Platinum 8280 to Intel Xeon Platinum 8180 family processors. Any difference in system hardware or software design or configuration may affect actual performance. April 2019.

[5] 3.0 TB per socket with HPE 512GB 2666 Persistent Memory Kit

[6] Supported by the 2nd generation Intel Xeon Scalable Processors

[7] Supported by the 1st generation Intel Xeon Scalable Processors

Informații suplimentare

ECC	Yes
RAID support	Yes
Hot-Plug support	Yes
Internal memory	32 GB
Memory clock speed	2933 MHz
Processor manufacturer	Intel
Optical drive type	No
Ethernet LAN	Yes
Memory layout (slots x size)	1 x 32 GB
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Internal memory type	DDR4-SDRAM
Execute Disable Bit	Yes
Intel Trusted Execution Technology	Yes
Sustainability certificates	ENERGY STAR
Processor frequency	2.1 GHz
Operating system installed	No
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Processor boost frequency	4 GHz
Processor cores	20
Number of processors installed	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
VGA (D-Sub) ports quantity	1
Processor family	Intel® Xeon® Gold
Number of HDDs supported	8
Ethernet interface type	10 Gigabit Ethernet
Maximum number of SMP processors	2
Rack mounting	Yes
Redundant power supply (RPS) support	Yes
Supported HDD sizes	2.5
Total storage capacity	0 GB
Remote administration	iLO 5 ASIC
Processor generation	2nd Generation Intel® Xeon® Scalable
Motherboard chipset	Intel® C621
Maximum internal memory	1.54 TB
Maximum storage capacity	26.4 TB
Chassis type	Rack (1U)
HDD interface	SATA, Serial Attached SCSI (SAS)
RAID levels	0, 1, 5, 6, 10, 50, 60
LAN controller	Broadcom 57416
Power Supply	800 W
Redundant fans support	Yes
Processor model	5218R
Processor cache	27.5 MB
Form factor	Rack 1U
Frecventa Procesor:	2.1 GHz
Familie Procesor	Xeon
Numar Nuclee	20
Capacitate RAM	32GB
Tip memorie RAM	DDR4
Capacitate HDD	None
Putere Sursa	800 W
Sistem de operare	None
Ethernet LAN (RJ-45) ports	2
Height	429 mm
Width	434.6 mm
Memory slots	24x DIMM
Depth	707 mm
Producator	HPE
Garantie	36
